Multihead Weigher Packing Machine

  • Fully Auto High Speed Weighing Packing Machine With Combination Weigher
  • Fully Auto High Speed Weighing Packing Machine With Combination Weigher
  • Fully Auto High Speed Weighing Packing Machine With Combination Weigher
  • Fully Auto High Speed Weighing Packing Machine With Combination Weigher
  • Fully Auto High Speed Weighing Packing Machine With Combination Weigher
  • Fully Auto High Speed Weighing Packing Machine With Combination Weigher
Fully Auto High Speed Weighing Packing Machine With Combination WeigherFully Auto High Speed Weighing Packing Machine With Combination WeigherFully Auto High Speed Weighing Packing Machine With Combination WeigherFully Auto High Speed Weighing Packing Machine With Combination WeigherFully Auto High Speed Weighing Packing Machine With Combination WeigherFully Auto High Speed Weighing Packing Machine With Combination Weigher

Fully Auto High Speed Weighing Packing Machine With Combination Weigher

  • Place of Origin: China
  • Brand Name: AUTOM
  • Certificate: CE/ISO/SGS
  • Model No: ATM-L520VW
  • Description: Fully Auto High Speed Weighing Packing Machine With Combination Weigher
  • INQUIRY   EMAIL

Fully Auto High Speed Weighing Packing Machine With Combination WeigherFully Auto High Speed Weighing Packing Machine With Combination Weigher

Fully Auto High Speed Weighing Packing Machine With Combination Weigher

Technical characteristics:

1. English and Chinese screen display, operation is simple.

2. PLC computer system, function is more stable, adjustment any parameters not need stop machine.

3. It can stock ten dispose, simple to change variety.

4. Sever motor drawing film, position accurately.

5. Temperature independent control system, precision get to±1°C.

6. Horizontal, vertical temperature control, suitable for various of complex film, PE film packing material.

7. Packing type diversification, pillow sealing, standing type, punching etc.

8. Bag–making, sealing, packing, print date in one operation.

9. Work circumstance quiet, low noise.

10. 4 sets of servo system (Panasonic brand) with continuous pulling film system, for pulling film, horizontal sealing jaws, the horizontal sealing system up, vertical sealing system and horizontal system up-down moving.

Application:

Suitable for packaging many different kinds of products; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, dried fruit, seed, small hardware, dumplings, vegetable, fruits and Sugar etc. which shape is roll, slice and granule.

Technical Parameters:

Model No.

ATM-L520VW

Packing speed (bags/min)

10-150bags/min

Max width of packing film (mm)

140mm-520mm

Packing pouch size(mm)

(L): 50-400mm (W): 60-250mm

Total power (kw)

4.8Kw

Filling range(ml)

150-1000ml

Max outside diameter of rolling film (mm)

≤φ400

Type of bag making

Pillow bag/gusset bag

Air consumption

0.8Mps 0.3m³/min

Packing film thickness(mm)

0.05-0.12

Gross weight(kg)

550Kgs

Machine dimension(mm)

(L)1315×(W)1023×(H)1343mm

Working voltage

220v 50hz

Packing film material

BOPP/CPP, BOPP/VMCP, BOPP/PE, PET/VMPET/PE, PET/PE, ect

AUTOMPACK’s mission is to keep developing intelligent vertical packaging machines and offer full automatic packaging solutions. till nowadays, we already have successfully developed over 25 types packaging machine included in pillow bag/gusset bag/quad seal bag/3 or 4 sides sealing bag, connected strip bag form fill seal bagger, a these equipment able to pack all different kinds of material such as most daily snacks, food, liquid, paste, Powder etc. forming and metal spares, high technical material, vegetable, etc. cover agriculture, industrial, manufacturing all sorts fields material and commodities to pack favorable through our vertical packing machine.
